X2 transceiver is an an early generation 10 gigabit interface related to the similar XENPAK format. It is intended for use in routers, switches and optical transport platforms. X2 may be used with 10 gigabit ethernet or OC-192/STM-64 speed SDH/SONET equipment. Our X2 series module include SR, LR, ER and ZR.
View details >The XENPAK MSA was publicly announced in year 2001, it is an early generation 10 gigabit interface. It has been gradually eliminated by the market because over large size, which not suitable for high density applications. Only some old switch models still have XENPAK port, our XENPAK series module include SR, LR, ER and ZR.
View details >100G Adaptor Module is designed for 100Gigbit Ethernet to deploy QSFP28 transceiver modules on equipment with CFP/CFP2 ports. With the adaptor module, it provides flexibility to use either CFP/CFP2 or QSFP28 module on a CFP/CFP2 port of a switch. X2/XENPAK to SFP+ Adapter Module enabling migration from X2/XENPAK to Small SFP+ form factor without having to upgrade or replace the switches. There are a limited amount of line cards and switches which are still using X2/XENPAK optics. Newer product line are smaller size XFP and SFP+. The converter module provides flexibility to use the 10 Gigabit X2/XENPAK interface port of a switch with SFP+ modules. This flexibility is important when the specific type of interface is not available or customers want to use the same form of factor for interfaces across multiple platforms deployed in their network.
View details >10G SFP+ dual fiber transceiver module include SR, LR, LRM, ER, ZR and EZR. SR for Multimode short distance, LR for long range, LRM support link length of 220m on Multimode fiber (MMF), ER means extended range, ZR module support link up to 80km, EZR for transmission distance up to 100km, 120km. These modules are compliant with MSA, SFF-8472, SFF-8431 and IEEE802.3ae. With features of low power consumption and high reliability which suitable for data center, metro network and service provider transmission applications.
View details >10G Bidi (Bi-Directional) transceiver modules operate on a single strand of SMF. The communication over a single strand of fiber is achieved by separating the transmission wavelength of the two devices. For 10km, 20km, 40km and 60km wavelength is 1270nm/1330nm. 80km is 1490nm/1550nm. Single fiber saves fiber resources compare with dual fiber one. Good cost performance, high reliability which suitable for data center, metro network and service provider transmission applications.
View details >Coarse Wavelength-Division Multiplexing Small Form-Factor Pluggable Plus (CWDM SFP+) solution is a convenient and cost-effective solution for the adoption of 10 Gigabit Ethernet in data-center and metropolitan-area access networks. There are 18 center wavelengths available from 1270 nm to 1610 nm, with each step 20 nm. Transmission distance from 10km, 20km, 40km up to 80km. Digital diagnostic functions are available via an I2C.
View details >10GBASE Dense Wavelength-Division Multiplexing SFP+ Modules it is designed for carriers and large enterprises with a scalable, flexible, cost-effective system for multiplexing, transporting high-speed data, storage, voice and video applications in point-to-point, add/drop and star network topologies. It operates at a nominal wavelength of 100GHz or 50GHz ITU Grid. Except fixed channel DWDM modules, also have Tunable DWDM SFP+, which can adjust its wavelength on site to the required lambda. Tunable DWDM SFP+ transceivers enable us to change wavelengths unlimited within the C-band DWDM ITU Grid.
View details >10GBASE XFP transceivers comply with XFP Multi-Source Agreement (MSA) Specification. Our XFP portfolio includes SR, LR, LRM, ER, ZR, CWDM, DWDM, Bidi series. XFP transceivers principal applications include 10 Gigabit Ethernet, 10G Fiber Channel, synchronous optical networking (SONET) at OC-192 rates and synchronous optical networking STM-64.
View details >
